SIN-H32: 32 inch RK3576 Android 14 wall mount signage display
Wall mount, portrait. RK3576, Android 14, 4GB + 32GB. OEM and ODM orders accepted.
- Model
- SIN-H32
- Screen
- 32"
- Chipset
- RK3576
- OS
- Android 14
- RAM + storage
- 4GB + 32GB
- Form
- Wall mount, portrait
- Minimum order
- 1
SIN-H32 specifications
Values as listed for the standard configuration. RAM, storage, OS version and peripherals are configured per order.
| System | |
|---|---|
| CPU | octa core RK3576 |
| RAM | 4GB |
| Internal memory | 32GB |
| Operation system | Android 14 |
| Touch screen | 10-Point capacitive touch |
| Display | |
| Panel | 32"LCD IPS panel |
| Resolution | 1920*1080 |
| Active area | 293.76(H)x165.24(V) |
| Display mode | Normally black,IPS |
| viewing angle | 80/80/80/80(L/R/U/D) |
| Contrast ratio | 700 |
| Luminance | 250cdm2 |
| Aspect Ratio | ,16:9 |
| Network | |
| WiFi | 802.11b/g/n |
| Ethernet | 100M/1000M |
| Bluet-ooth | Blue-tooth 4.0 |
| Interface | |
| USB Device | Micro USB OTG |
| Power Jack | DC power input |
| RJ45 | RJ45 |
| Earphone | 3.5mm earphone |
| Media plays | |
| Video format | MPEG-1,MPEG-2,MPEG-4,H.263,H.264,VC1,RV etc.,support up to 4k |
| Audio format | MP3/WMA/AAC etc. |
| Photo | jpeg |
| Other | |
| Wall mounting bracket | 100mm*100mm wall mounting |
| NFC | 13.56M(Optional) |
| Button | POWER/VOLUME+/VOLUME-/CALL |
| Speaker | 2*2W |
| Camera | 2.0M/P,Front camera |
| Micphone | yes |
| Language | Multi-language |
| Working temp | 0--40degree |
| Accessories | |
| Adapter | Adapter,12V/1A |
| User manual | yes |
Configured per order
RAM and storage tier, Android version within the chipset range, PoE, NFC, camera and 4G are set when the order is placed. The table shows the listed standard configuration.
Software
Standard AOSP Android. Custom launcher, boot logo, preloaded apps, open ADB and builds without GMS are available through OEM firmware.
Specify these in your inquiry
- RAM and storage tier. Several models list two tiers.
- Android version. It follows the chipset, see the OS column.
- PoE, NFC, camera, 4G: optional on many models.
- GMS or AOSP, launcher lock-down, ADB access.
- Housing color and logo method.
- LCD products carry a 1 year warranty.
Where the SIN-H32 fits and where it does not
The sin-h32 is a 32 inch RK3576 Android 14 wall mount signage display. We build it for fixed portrait or landscape installations where a larger panel works better than a 21 inch or 24 inch unit. Think lobby directories, meeting room schedules, menu boards, or wayfinding. The RK3576 octa core gives it enough headroom for 4K video decode. The panel itself is 1920 by 1080, so content is downscaled. That's fine for signage but not for fine text at close range.
A buyer who needs a portable tablet should look at our 10 inch Android tablets instead. Need a desktop kiosk? The SIN-H32 doesn't have a stand. We also don't make this model in a battery version or with a VESA mount larger than 100 mm by 100 mm. Working temperature is 0 to 40 degrees Celsius. Indoor use only. For outdoor or semi-outdoor, our outdoor LED displays are a different product line.
We state these limits because a spec table can't show them. Your project needs a brighter panel, a different aspect ratio, or a touch overlay? The SIN-H32 may not be the right model. We'd rather you ask before ordering than find out after integration.
What to specify when ordering the SIN-H32
An RFQ for the 32 inch RK3576 Android 14 wall mount signage display should include more than the model name. Tell us the mounting orientation-the default wall bracket assumes portrait, but landscape is common. Confirm the touch requirement. The table lists 10-point capacitive touch; if you don't need touch, we can quote a non-touch version. NFC is optional at 13.56 MHz, so say if you want it.
Software matters. We ship Android 14 without Google Mobile Services unless you ask. We can preload your APK, set a custom launcher, open ADB, or adjust boot animation. Give us the APK and your desired behavior. Need kiosk mode? We can lock the device to one app. The system has 4GB RAM and 32GB storage. If your app needs more storage, tell us; we can discuss larger eMMC.
Specify any housing color or logo too. Our OEM scope covers silk print, metal badge, and carton design. Don't send a vague request like "customize it". List what changes from the standard unit. That helps us quote accurately and avoid surprises. For any model comparison, see our 32 inch Android tablet category.
How the SIN-H32 differs from sibling models
The SIN-H32 is not the only wall mount Android device we make. The WA8058T is a smaller panel with a different chipset. That one suits lighter signage tasks. The HP1012T is a 10 inch model aimed at desk or counter use. The WA1036T and WL1026T are also 10 inch. But one is a rugged tablet and the other a wall mount panel. None of them share the SIN-H32's 32 inch panel or RK3576 processor.
Need a slightly smaller wall mount? Our 27 inch Android tablets may fit. The SIN-H32 has a 250 cd/m2 luminance-standard for indoor units. Don't expect a sunlight readable display. For applications that need a built in stand or L shape design, we have other series. The SIN-H32 is a flat panel with a wall bracket only.
Choosing between these models comes down to size, processor, and mounting. We list all specs on each model page, so you can compare before you ask. If you're not sure, send us your use case and we'll point to the right model.
