HS-SHT1568: 15.6 inch RK3288 smart home Android tablet
Wall mount. RK3288 Quad-core Cortex A17, 1.6GHz, Android 8.1, 2GB + 8GB. OEM and ODM orders accepted.
- Model
- HS-SHT1568
- Screen
- 15.6"
- Chipset
- RK3288 Quad-core Cortex A17, 1.6GHz
- OS
- Android 8.1
- RAM + storage
- 2GB + 8GB
- PoE
- Yes
- Form
- Wall mount
HS-SHT1568 specifications
Values as listed for the standard configuration. RAM, storage, OS version and peripherals are configured per order.
| Processor | RK3288 Quad-core Cortex A17, 1.6GHz |
|---|---|
| RAM | 2GB |
| Storage | 8GB (SD card expandable) |
| Operating System | Android 8.1 (supports 6.0/7.1/9.0) |
| Display | 15.6" LCD Panel, 1280*800, 16:10 |
| Touch | 10-Point Capacitive Touchscreen |
| Brightness | 350cd/m² |
| Contrast Ratio | 1000:1 |
| Viewing Angle | 85°/85°/85°/85° (L/R/U/D) |
| WiFi | 802.11 b/g/n |
| Ethernet | 100M/1000M RJ45 with POE (IEEE802.3at/af) |
| Bluetooth | Bluetooth 4.0 |
| Camera | 2MP Front Camera |
| Audio | 3.5mm Earphone + Microphone, Stereo Speakers |
| Interfaces | SD Card, USB Host, Micro USB OTG, USB Serial |
| Power | DC 12V Input |
Configured per order
RAM and storage tier, Android version within the chipset range, PoE, NFC, camera and 4G are set when the order is placed. The table shows the listed standard configuration.
Software
Standard AOSP Android. Custom launcher, boot logo, preloaded apps, open ADB and builds without GMS are available through OEM firmware.
Specify these in your inquiry
- RAM and storage tier. Several models list two tiers.
- Android version. It follows the chipset, see the OS column.
- PoE, NFC, camera, 4G: optional on many models.
- GMS or AOSP, launcher lock-down, ADB access.
- Housing color and logo method.
- LCD products carry a 1 year warranty.
HS-SHT1568: where this 15.6 inch RK3288 smart home Android tablet fits
The hs-sht1568 is a fixed wall mount panel. It's for scenes that need a 15.6 inch screen and a wired network connection without a separate power run. Because it carries IEEE802.3at/af PoE on the RJ45 jack, you can feed data and 12V-class power through one Ethernet cable. That matters when the tablet sits in a wall box, at a door station, or behind a mirror where a local outlet is ugly or hard to pull.
We position this model for smart home dashboards, room control, visitor entry, and simple kiosk duty. The 1280x800 panel with 350cd/m² brightness is comfortable in indoor light. The 10-point capacitive touch and front camera cover basic interaction and video calls. It's not a high-brightness or rugged device. We don't pretend otherwise.
If your job needs a desk stand, a battery, or outdoor daylight readability, this is the wrong model. Our 15-inch Android tablets category shows other options. For a panel that must survive drops, dust, or wet hands, look at rugged Android tablets.
What to specify when you order the HS-SHT1568
Tell us three things in your RFQ: the Android build you want, the mount details, and any peripheral additions. Base OS is Android 8.1. We can ship builds for 6.0, 7.1, or 9.0. Standard firmware is AOSP without Google Mobile Services. Need open ADB, a custom launcher, or preloaded apps? Say so up front.
Mounting is a wall mount form. We need the cutout or bracket dimensions from you, or we can supply our standard wall bracket. If the tablet goes into a flush box, specify box depth. The rear I/O and PoE jack add thickness.
Options that come per order include NFC, RFID, a barcode scanner, a fingerprint reader, 4G, and a different camera. Base unit has 2GB RAM and 8GB storage with an SD card slot. If your app is heavy, tell us now; this board isn't a fast multitasker.
Send the full spec, the expected quantity, and your target market.
How the HS-SHT1568 differs from sibling 15.6 and smart home models
Our tablet line has several 15.6 inch panels. Not interchangeable, though. The WA8058T runs a different chipset, aimed at general commercial use. But the WA1036T and WL1026T? Those are 10.1 inch models. They fit smaller wall space, sure, but you get less screen. The HS-SHT1568 is the only one in this group with PoE as a standard feature. That's why it lands on our PoE Android tablets page and the smart home panel page.
The RK3288 is an older quad-core A17. It handles a single control UI fine. Or a video stream. Or a booking screen. But if your app needs heavy browser tabs, live 4K video, or fast UI transitions? Pick a model with RK3399 or RK3568. We'll say that plainly in the quote. Don't order this board for a job that needs a modern GPU.
One limit: the panel is 16:10, not 16:9. Your UI layout should account for that. Otherwise the screen will letterbox or stretch.
